Service: Level 2 EV Charger Installation – 60A Circuit
Location: Asheville, NC (Garage)
Completed: November 26, 2024
Technicians: Wyatt Barnes, Grady Houston
Branch: Hendersonville (Charlotte business unit)
Project overview
Our Hendersonville team completed a dedicated Level 2 EV charging circuit for homeowner Aaron Dishman in Asheville, NC. The installation was designed for a 60-amp load to support high-performance Level 2 chargers and future vehicle upgrades, all while meeting local electrical code and utility rebate requirements.
- Installed a new 60A breaker in the home’s electrical panel
- Routed approximately 50 ft of 3/4 in EMT conduit for a clean, durable surface run in the garage
- Pulled #6 THHN conductors sized for a 60-amp EV circuit
- Dedicated branch circuit for a customer-supplied Level 2 EV charger
- Electrical permit filed and inspection-ready
- Documentation prepared to be Duke Energy rebate ready
Why a 60A Level 2 circuit?
A 60-amp Level 2 circuit offers faster home charging and room to grow. Many premium Level 2 EVSE units are designed to deliver up to 48A continuous charging (on a 60A breaker), reducing charge times and supporting multi-EV households or longer daily commutes.
- Faster charging: Significantly cuts overnight charge time vs. lower-amp circuits
- Future-ready: Supports higher-output chargers and newer EV models
- Code-conscious: Proper conductor sizing and overcurrent protection for long-term safety
How we completed the installation
- Assessment & layout: Confirmed panel capacity and mapped out a neat, low-profile conduit path in the garage.
- Permitting: Filed the electrical permit with the local authority to ensure compliant installation and smooth inspection.
- Conduit & wiring: Mounted 3/4 in EMT with appropriate fittings and supports, then pulled #6 THHN conductors to the charger location.
- Panel work: Installed and labeled a new 60A breaker dedicated to the EV circuit.
- Testing: Verified polarity, grounding, breaker operation, and EVSE functionality to confirm safe, reliable operation.
- Inspection-ready: Prepared the job for final inspection and homeowner documentation.
The result is a clean, professional garage installation that blends into the space while delivering robust charging performance.
Duke Energy rebate ready
This project was set up to meet typical Duke Energy Level 2 charging rebate requirements, helping the homeowner capture available incentives. Our team provided the necessary installation details and documentation so the customer can apply for the rebate with confidence.
Permits and local requirements
Touchstone Electric handled the electrical permit for this Asheville project. Depending on your jurisdiction and scope, additional non-electrical permits (such as historic preservation or zoning) may be required and are separate from the electrical permit. If other approvals are needed, we’ll advise you on next steps and can assist with processing when requested.
Serving Asheville, NC
As a local residential contractor, Touchstone Electric’s Hendersonville branch delivers fast scheduling, code-compliant workmanship, and clear communication for EV charging projects throughout Asheville, NC. From panel evaluations and load calculations to neat conduit runs and rebate-ready paperwork, we make home charging straightforward.
Considering a Level 2 EV charger for your home in Asheville? Our team can assess your panel, recommend the right circuit size, and complete a professional installation that’s built to last.
