Level 2 EV Charging Outlet Installed in Charlotte, NC
Touchstone Electric’s Charlotte team completed a clean, code-compliant Level 2 EV charger outlet installation for Duke Energy - Allumia in Charlotte, NC. On April 21, 2025, our licensed technician, Easton Mitchell, installed a 50-amp NEMA 14-50 receptacle on a dedicated circuit to deliver fast, reliable home charging.
This project was serviced by our Matthews branch, proudly supporting homeowners and businesses throughout the greater Charlotte area.
What We Installed
- NEMA 14-50 Level 2 outlet for 240V EV charging compatibility.
- Dedicated 50-amp breaker installed in the main panel to protect the new circuit and ensure safe operation.
- Approximately 25 feet of 6/3 NM-B Romex to supply the outlet with the appropriate conductor size for a 50-amp load.
- Direct drop beneath the garage panel to minimize run length and provide a tidy, efficient layout.
- Permit obtained and installation completed in accordance with local electrical code.
The result is a robust, future-ready charging point that works with many portable EV charging cords designed for NEMA 14-50 receptacles.
How We Completed the Work
- Load and panel review: Verified capacity and selected the correct two-pole breaker for the new circuit.
- Dedicated circuit routing: Ran 6/3 NM-B Romex from the panel to the new outlet location with secure supports and proper protection at penetrations.
- Outlet placement: Mounted the NEMA 14-50 receptacle in a convenient garage location directly below the panel for a clean, efficient install.
- Terminations and labeling: Torqued connections to manufacturer specifications and labeled the new circuit at the panel.
- Code compliance: Performed workmanship to meet current electrical code and arranged permitting as required.
Every Touchstone Electric EV charging install is planned for safety, convenience, and long-term reliability—so you can plug in and charge with confidence.
Why Choose a NEMA 14-50 for Level 2 EV Charging?
- Faster charging at home: A 240V, 50-amp circuit significantly reduces charge times compared to standard 120V outlets.
- Flexibility: Many EV owners use their vehicle’s portable Level 2 cord with a NEMA 14-50 plug, avoiding a hardwired-only solution.
- Future-ready: The dedicated 50-amp circuit supports a wide range of current EVs and charging equipment.
Rebates, Permits, and Local Expertise
Our Charlotte team stays current on local permitting requirements and utility programs. For this project, we handled the permitting and assisted with program documentation as needed. Incentives and eligibility can change, so our team is happy to help you navigate available options when you schedule an estimate.
Technician Who Performed the Work
Easton Mitchell, one of our Charlotte-based electricians, completed this installation with a focus on neat routing, proper terminations, and adherence to code.
Customer Feedback
The customer praised our work with a positive review. You can read it here: Read the review on Google.
Serving Charlotte, NC
From our Matthews branch, Touchstone Electric provides EV charging solutions across Charlotte, NC. Whether you need a NEMA 14-50 outlet or a hardwired Level 2 charger, our team delivers professional installations tailored to your panel capacity, parking layout, and charging goals.
Considering an upgrade? Contact our Charlotte team to plan a safe, code-compliant Level 2 charging setup that fits your home and your EV.
