Huntersville 200 Amp Electrical Panel Upgrade with Surge Protection

In April 2025, Touchstone Electric’s Charlotte team (Matthews branch) completed a permitted 200 amp panel upgrade for a home in Huntersville, NC. Lead electrician Christian Cedillos replaced the aging main panel, enhanced the grounding system, installed new breakers sized for the home’s loads, and fitted a whole‑home surge protector for comprehensive protection.

What we did for this Huntersville home

Installed a new indoor 200A main panel (aluminum) and brought it up to current electrical code. We grounded and bonded the panel, properly labeled circuits, and safely reconnected the service entrance conductors and existing branch circuits.
Added a whole‑home surge protector at the main panel to divert damaging surges to ground and help protect sensitive electronics and appliances.
Upgraded the grounding system by driving an additional ground rod and installing a continuous grounding electrode conductor (GEC) routed to the main service panel.
Replaced and added breakers to match the home’s loads: 9× 15A for lighting and standard circuits, 4× 20A for small appliances, 3× 30A double‑pole for larger equipment, and 1× 50A for high‑demand appliances.
Handled permitting and inspection with the local authority to ensure the upgrade meets all requirements.
Maintained essential power options during the outage window by making a generator available for limited use while the panel change‑out was performed.

Why upgrade to a 200 amp panel?

A 200A service provides headroom for today’s electrical needs—HVAC, kitchen remodels, EV charging, and future projects—while reducing nuisance tripping and enhancing overall reliability. This upgrade also improves safety by replacing aging equipment, correcting labeling, and ensuring proper bonding and grounding throughout the service equipment.

Code‑compliant grounding and bonding

To meet current code and improve fault clearing performance, our team drove a new ground rod (typically about 8 feet) and installed a continuous GEC to the main service panel. We kept the GEC routing within the required distance and verified secure terminations at the grounding and bonding points. Proper grounding helps stabilize voltage, supports surge mitigation, and is essential for the safe operation of the electrical system.

Whole‑home surge protection for appliances and electronics

We installed a panel‑mounted surge protective device that shunts excess voltage from events like nearby lightning activity, utility fluctuations, or large appliances cycling. This helps prevent cumulative damage that can shorten the life of electronics and major equipment.

The installed device includes $10,000 in coverage over 3 years for covered equipment in the unlikely event of failure. Coverage is secondary to the homeowner’s existing insurance and excludes direct lightning strikes. Typical covered items may include major appliances, HVAC components located inside the home, and hard‑wired devices when protected by the properly connected device.

Breaker updates and AFCI considerations

We matched new breakers to the home’s loads and labeling for a clean, safe layout. As local inspectors continue implementing NEC 2020, some circuits may require AFCI protection. In certain homes, existing wiring conditions (such as shared neutrals) can cause immediate tripping with AFCI breakers. If that occurs, our licensed electricians can diagnose and correct the underlying issue to bring the circuit into compliance.

Materials and workmanship

The upgrade included appropriately rated conductors—such as XHHW 4/0 stranded—for reliable service and grounding connections. The aluminum 200A panel installed on this project carries a 20‑year transferable panel warranty, and our team coordinated the permit and inspection for a smooth, code‑compliant finish.

Customer experience

Ashton Holbrook praised our team with a positive review following the project. We appreciate the trust and are proud to deliver clean workmanship, clear communication, and safe, code‑compliant results for Huntersville homeowners.

Serving Huntersville from our Charlotte team

Touchstone Electric’s Charlotte team, operating from our Matthews branch, regularly performs panel replacements, service upgrades, grounding improvements, and surge protection installations across Huntersville, NC. If you’re planning an electrical panel upgrade, need room for future loads, or want to add whole‑home surge protection, our local electricians are ready to help.
