Project overview
Touchstone Electric’s Charlotte team out of our Matthews branch completed a comprehensive electrical upgrade in Monroe, NC for homeowner Gayle Walsh. On November 4, 2025, our licensed electricians Jose Rodriguez and Theo Coetsee replaced the indoor main service panel with a 200 amp copper-bus panel, installed whole-home surge protection, added a new grounding system, and replaced key breakers. The project was fully permitted and passed inspection for safety and code compliance.
Scope of work completed
- 200 amp indoor main panel (copper bus): The new panel was brought to current electrical code. We grounded and bonded the panel, reconnected the service entrance cable, reconnected existing branch circuits, and clearly labeled the new panel directory for easier future service.
- Whole-home surge protection: Installed and supplied a surge protector to help safeguard appliances and electronics during utility or lightning surges. Includes a $10k warranty on the surge protector.
- New grounding system: Installed a code-compliant grounding system to improve fault clearing and overall system safety.
- Breaker replacement and right-sizing:
- 6x 15 amp standard breakers for general lighting and bathroom circuits
- 10x 20 amp standard breakers for small-appliance branch circuits
- 3x 30 amp double-pole breakers for larger 240V loads
- 1x 100 amp double-pole breaker for a subpanel
- 1x 25 amp double-pole breaker for a small condenser, well pump, or mini-split
- Permits and inspections: We handled permitting, coordinated the utility shutdown, and scheduled inspection. Limited generator support was available during the outage window to keep essentials running.
Why this upgrade benefits Monroe homeowners
- Safety first: A modern, copper-bus 200 amp panel improves heat dissipation and connection integrity, reducing the risk of arcing and overheating.
- Stronger protection: Whole-home surge protection adds a first line of defense against damaging voltage spikes that can shorten equipment life.
- Reliable grounding: A new grounding system enhances fault-path performance, helping breakers trip as intended.
- Capacity and clarity: Right-sized breakers and a labeled panel support present needs and future additions like HVAC equipment, workshop tools, or EV charging.
- Future-ready compliance: As inspectors adopt NEC 2020 requirements, we advise on any needed AFCI/GFCI updates and can diagnose preexisting wiring issues (such as shared neutrals) that may affect advanced protective breakers.
About the equipment and materials
The new 200 amp indoor panel features a durable copper bus. The copper panel includes a 50-year manufacturer warranty. The installed surge protector includes a $10k warranty. All components were selected to meet current code and the home’s load requirements.
Our process in Monroe, NC
From our Matthews branch, we carefully planned the cutover to minimize downtime, safely de-energized the service, completed the panel swap and grounding work, installed surge protection, and reconnected circuits with clear labeling. After thorough testing, we coordinated inspection to confirm compliance and performance.
Customer feedback
We’re grateful that Gayle Walsh praised our work with a review. Read their feedback on Google: View the Google review.
Serving Monroe with expert panel upgrades
Whether you need a service upgrade, surge protection, or breaker diagnostics, Touchstone Electric’s Charlotte team proudly serves Monroe, NC and the surrounding area with code-compliant, homeowner-friendly solutions.
